Non-alloy/general structural steel
DIN EN 10 025-2
Our non-alloy structural steels are ideal for bending and folding, offering a wide range of applications. At thyssenkrupp Steel, you can order non-alloy structural steels with either pickled or unpickled surfaces to meet the specific requirements of your projects.
| Steel grade |
Standard designation |
THICKNESS1 from _ to in mm |
WIDTH1 from _ to in mm |
|---|---|---|---|
| S235 | S235 | 1.50 – 25.00 | 50 – 2,030 |
| S275 | S275 | 1.50 – 25.00 | 50 – 2,030 |
| S355 | S355 | 1.50 – 25.00 | 50 – 2,030 |
Normalized rolled fine-grain structural steel
DIN EN 10 025-3
The normalized fine-grain structural steels from thyssenkrupp Steel have a minimum yield strength of 275 to 355 MPa. These steels are characterized by good weldability and are used in components that require high strength.
| Steel grade |
Standard designation |
THICKNESS1 from _ to in mm |
WIDTH1 from _ to in mm |
|---|---|---|---|
| S275N/NL2 | S275N/NL | 1.50 – 16.00 | 50 – 2,030 |
| S355N/NL2 | S355N/NL | 1.50 – 16.00 | 50 – 2,030 |
Structural steel with teardrop pattern
DIN EN 10363
Tear-patterned structural steel from thyssenkrupp Steel offers an exceptionally slip-resistant surface, even on wet ground. Therefore, steel tear plates are used in the industry for a variety of applications: in the construction of platforms, ramps, and podiums, as well as for flooring and stairs.
| Steel grade |
Standard designation |
THICKNESS1 from _ to in mm |
WIDTH1 from _ to in mm |
|---|---|---|---|
| S235+AR | S235+AR | 3.00 – 12.00 | 1,000 – 2,030 |
| S275+AR | S275+AR | 3.00 – 12.00 | 1,000 – 2,030 |
| S355+AR | S355+AR |
1 Not all thickness and width combinations possible
2 Steel grade on request
On request
