Delivery forms and dimensions
Cold-rolled sheet
Tolerances according to DIN EN 10 131
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.40 – 4.00 | 600 – 1,950 | - |
| Sheet | 0.40 – 4.00 | 600 – 1,800 | 500 – 6,500 |
| Slit strip | 0.40 – 4.00 | 20 – 600 | - |
Electrolytically coated sheet
ZE/EG Zink
Tolerances according to DIN EN 10 131
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.40 – 2.5 | 600 – 1,950 | - |
| Sheet | 0.40 – 2.5 | 600 – 1,800 | 500 – 6,500 |
| Slit strip | 0.40 – 2.5 | 20 – 600 | - |
Hot-dip coated sheet
Z/GI Zink
Tolerances according to DIN EN 10 143
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.30 – 4.00 | 600 – 1,950 | - |
| Sheet | 0.30 – 4.00 | 600 – 1,800 | 500 – 6,000 |
| Slit strip | 0.30 – 4.00 | 20 – 600 | - |
Hot-dip coated sheet
ZF/GA Galvannealed
Tolerances according to DIN EN 10 143
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.50 – 2.60 | 600 – 1,950 | - |
| Sheet | 0.50 – 2.60 | 600 – 1,800 | 500 – 6,000 |
| Slit strip | 0.50 – 2.60 | 20 – 600 | - |
Hot-dip coated sheet
ZA galfan®
Tolerances according to DIN EN 10 143
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.40 – 3.00 | 700 – 1,600 | - |
| Sheet | 0.40 – 3.00 | 700 – 1,600 | 500 – 6,000 |
| Slit strip | 0.40 – 3.00 | 20 – 600 | - |
Aluminum-silicon coated sheet
AS
Tolerances according to DIN EN 10 143
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.30 – 3.00 | 600 – 1,600 | - |
| Sheet | 0.30 – 3.00 | 600 – 1,600 | 500 – 6,000 |
| Slit strip | 0.30 – 3.00 | 20 – 600 | - |
Hot-dip coated sheet
ZM Ecoprotect®
Tolerances according to DIN EN 10 143
| THICKNESS1 from_to in mm |
WIDTH1* from_to in mm |
LENGTH from_to in mm |
|
|---|---|---|---|
| Strip | 0.30 – 3.00 | 600 – 1,650 | - |
| Sheet | 0.30 – 3.00 | 600 – 1,650 | 500 – 6,000 |
| Slit strip | 0.30 – 3.00 | 20 – 600 | - |
1 Further thicknesses/dimensions on request
* Depending on the steel grade and thickness
