Soft steels for cold forming – optimal materials for precise and efficient forming processes

Hot-rolled mild steels for cold forming

Mild steels for cold forming – also known as cold-forming steels or deep-drawing steels – are the ideal choice for applications that require the highest dimensional accuracy, excellent surface quality, and outstanding formability.

Thanks to their fine-grained structure and consistent mechanical properties, sheets made from hot-rolled mild steel can be easily bent, drawn, and punched without the risk of cracks or distortions.

thyssenkrupp Steel supplies mild steels according to DIN EN 10111 (DD11 to DD14) and VDA 239-100 (HR2).

High-quality hot-rolled steels for cold forming in sheet metal processing

Typical applications of mild steels for cold-forming

Mild steels are widely used in a variety of cold-forming applications thanks to their versatility and reliability. Typical uses include body components such as doors, fenders, and panels, as well as numerous automotive parts like brackets and consoles. In mechanical engineering, mild steels are frequently employed for housings, containers, and covers. They are also ideally suited for the production of deep-drawn components in various technical systems, where precision and material consistency are essential.

Key advantages of mild steels

Mild steels offer a range of benefits that make them a preferred choice for industrial and automotive applications. Their excellent deep-drawing properties enable precise shaping without material failure, while the uniform sheet thickness and consistent material structure ensure predictable forming behavior. The high surface quality allows for superior finishing and coating results, and their outstanding processability ensures smooth performance in automated production lines.

Mild non-alloy steel for cold forming
DIN EN 10111 (previously DIN 1614-1)

­
Steel grade designation
­
Standard designation
THICKNESS1
from _ to in mm
WIDTH1
from _ to in mm
DD11 DD11 (previously StW22) 1.50 – 16.002 50 – 2,030
DD12 DD12 (previously RRStW23) 1.50 – 16.002 50 – 2,030
DD13 DD13 (previously StW24) 1.50 – 16.002 50 – 2,030
DD14 DD14 1.50 – 16.002 50 – 2,030
1. Not all thickness and width combinations possible. | 2. Acc. to DIN EN 10111 only up to d = 11,00 mm, for d > 11,00 mm in based on DIN EN 10111.

Deep-drawing steel
VDA 239-100

­
Steel grade designation
­
Standard designation
THICKNESS1
from _ to in mm
WIDTH1
from _ to in mm
HR2 HR2 1.60 – 6.00 50 – 2,030
1. Not all thickness and width combinations possible.
