thyssenkrupp Steel Heavy Plate Antwerp N.V.

thyssenkrupp Steel Heavy Plate Antwerp N.V., which is located in the port of Antwerp and has around 25 employees, is specialized in cutting high-strength hot-rolled strip to length.

Products and facilities

The premises include a 8,000 square meter shop housing a state-of-the-art cut-to-length line. It can process coils into high-strength hot-rolled sheets with a tensile strength up to 1,700 MPa in dimensions from 2 to 20 mm thickness, width from 700 to 2,100 mm and lenght from 1,000 to 16,000 mm. The Belgian site has optimum water, rail and road links.

Production steps in detail
1. Decoiler

The decoiler serves to unwind the coil, it is suitable for coils with an inside diameter of 600 to 880 mm.

2. Pre-leveling machine

The first leveling operation ensures the finished plates display good flatness and low residual stresses.

3. First brushing machine

The first brushing machine is used to remove loose scale. This serves to reduce dust so as to prevent indentations in the surface during the precision leveling process.

4. Squaring shear

Here scrap material is removed from the ends of the coil.

5. Double trimming shear

The double trimming shear serves to trim the coil edges. A width tolerance of 2 mm can be achieved.

6. Precision leveling machine

Three leveler cassettes with different roll diameters and roll numbers are available for different thicknesses and grades. They are used to ensure the finished plates are flat and stress-free.

7. Second brushing machine

The second brushing machine is used to remove loose scale after precision leveling. Reducing the steel dust optimally prepares the plates for laser processing.

8. Cut-to-length shear

Here the coil is cut into plates of 1,000 to 16,000 mm in length. Closer than standard length tolerances can also be agreed.

9. Stacker

The stacker is used to stack the plates into packs. A vacuum lifter transfers the plates from roller table to stack to avoid magnetization and guarantee an outstanding, scratch-free surface.
